Boring Machines
WFT 13/15 (R,L)
Most popular FERMAT table-type horizontal boring mill, for high-performance machining with maximum utilization of accessories and automatic milling heads for efficient machining of workpieces of up to 20 tons.
- Spindle diameter 130 mm or 150 mm; spindle travel 800 mm.
- Optional ram stroke 700 mm.
- Powerful and precise milling, coordinate drilling, boring, and threading.
- Extremely versatile series of table-type horizontal boring mills, fully compatible with a wide range of accessories and automatic milling heads.
|
|
units | WFT 13/15 | ||
| Spindle diameter | mm | 130 | 150 | |
| Spindle taper |
|
SK 50 (DIN, MAS 45°, ANSI)/BIG+/HSK100 | ||
| Spindle speed (max.) | rpm | V130 - 3400 (opt. 4000) | V150 - 3000 (opt. 3500) | |
| Main Power Heidenhain or SIEMENS CNC (S1/S6) | kW | 41/61.5; 53/77.9 | ||
| Max. Torque Heidenhain or SIEMENS CNC (S1/S6) | Nm | 2099/3149; 2713/3989 | ||
| Main Power FANUC CNC (S1/S3) | kW | 37/45; 53/77.9 | ||
| Max. Torque FANUC CNC (S1/S3) | Nm | 2210/2687; 2713/3989 | ||
| X-axis Cross Travel of Table | mm | 2000/3000/4000/5000/ (optional for 25-50T 6100/6300) | ||
| Y-axis Vertical Travel of Headstock | mm | 2000/2500/3000/3500 | ||
| Z-axis Longitudinal Travel of Column | mm | 1500/2000/2500/3000 | ||
| W-axis Spindle Travel | mm | 800 | ||
| Ram stroke in V-axis (optional) | mm | 700 (for WFT R) | ||
| Rapid Feed X, Y | mm/min. | 12000, 12000 (box GW); 20000, 15000 (Lin. GW Standard); 20000, 25000 (Lin GW Exclusive) | ||
| Rapid Feed Z, W | mm/min. | 8500, 10000 (box GW); 20000, 10000 (Lin. GW Standard); 25000, 10000 (Lin GW Exclusive) | ||
| Rapid Feed V |
mm/min
|
10000
|
||
| Rapid Feed B | rpm | 2 (opt. 5) | ||
| Max. Table Load | kg | 20000 (opt. 10000, 25000, 50000) | ||
| Table Size T20 | mm |
1600 x 1800/1800 x 2200/1800 x 2600/2000 x 2400/2500 x 2500/2000 x 3000 |
||
| Table Size T25-50 |
mm
|
2000 x 2000/2000 x 2500/2000 x 3000/2500 x 2500/2500 x 3000/2500 x 3500/3000 x 3000/3000 x 3500/3500 x 3500/2500 x 5000
|
||
| Table Size T10
|
mm | 1200x1200, 1200x1400, 1400x1600, 1600x1600, 1400x1800, 1600x1800 | ||
