Angle Heads and Facing Heads
OHA S 2.5
Orthogonal automatic angle head with positioning of 2.5°, compatible also with small headstocks of WFC 10, WFT 11 and WFT 13.
- Automatically attached to the headstock, automatic positioning, automatic tool clamping and unclamping.
|
|
units |
OHA S
|
|
Revolutions
|
rpm |
10-4000 |
| Tool Taper | - | SK 50 (DIN, MAS 45°, ANSI)/BIG+/HSK100 |
| Tool Clamping Force | kN | 20±15% |
| Positioning | ° | 2.5/2.5 |
- Outside Coolant: standard
- Coolant Through Spindle: optional
- Lubrication: manual by grease
Gallery
